Freight (Goods) Elevators EVA 600 Series

EVA 600 range of industrial and commercial goods lifts can effortlessly move things around your building.

Whether it’s in a hospital, shopping centre, warehouse, industrial setting, office building or hotel, our elevators deliver quiet and efficient service, 24 x7

Freights & Goods lift solutions refers to the use of an elevator in an industrial environment in order to facilitate the movement of large, heavy items. Without lifts that have been designed specifically to handle the weight and bulk of the items themselves, it would be impossible for any factory, warehouse or storage facility with more than one floor to function on a day-to-day basis.

Considering the fact that the load they’ll be carrying is much greater than the equivalent in a residential or commercial environment, the lifts are heavily reinforced in order to cope with the more strenuous demands made of them.

No matter what kind of heavy industry your organisation is involved with, you can trust that we’ll be able to help you to meet — and exceed — your expectations.

The EVA 600 can be adapted to accommodate both the operational load of goods, and also accompanying passengers as needed.

When the safe, efficient and repeated movement of goods is crucial to a business we can help – protecting staff from the stresses and strains of manual handling.

    Our freight lifts find applications in –

  • Warehouses
  • Industrial premises
  • Shopping centres
  • Hotels
  • Office Buildings

Rugged construction

Reliability of performance, endurance to large freights and harsh work conditions

Customised solution

We design as per your existing building architecture and structural needs

Outstanding ride quality

Premium quality and exceptional ride comfort are delivered by both a gearless motor and a state-of-the-art inverter.

Spatial efficiency

Optimum space efficiency by offering the option of a larger car installation in a standard shaft for rated loads up to 2000kg.

Safety

Light curtains provide additional safety and protection to the passenger when the car doors are closing. Set an automatic return to floor

Emergency evacuation

In the unlikely event of power failure, the emergency evacuation system ensures the safe transportation of passengers to the nearest floor where the doors automatically open as to allow the car exit.

High-capacity Machine

Equipped with a machine lifting system, especially designed to facilitate the installation of high rated load lifts, hence, larger motors.

3000 kg Rated load

0.5 m/s Max speed

9 Max stops

24m Max travel

Car and Landing Door Collapsible doors

Load (Kg) Car Width (mm) Car Depth (mm) Hoistway Width (mm) Hoistway Depth (mm) Door Entrance Width(mm) Door Entrance Height(mm)
500 1200 1100 1960 1375 1100 2000
1000 1600 1570 2420 1855 1400 2000
1500 1900 1800 2720 2080 1700 2000
2000 2100 2025 2920 2300 1700 2000

Car and Landing Auto Telescopic doors

Load (Kg) Car Width (mm) Car Depth (mm) Hoistway Width (mm) Hoistway Depth (mm) Door Entrance Width(mm) Door Entrance Height(mm)
500 1200 1100 1960 1580 1100 2000
1000 1600 1570 2420 1970 1400 2000
1500 1900 1800 2720 2290 1700 2000
2000 2100 2025 2920 2510 1700 2000
